UGREEN CM511 (35999) 6-in-1 USB-C Docking Station

UGREEN CM511 (35999) 6-in-1 USB-C Docking Station Price in Bangladesh

Top Highlights

• 4K@60Hz HDMI OutputConnect one compatible high-resolution external display.
• Four 10Gbps USB PortsTwo USB-A and two USB-C data connections.
• 100W Power Delivery InputSupports laptop charging passthrough.
• Compact Aluminum DesignConvenient expansion for mobile and desk setups.

About the UGREEN CM511 (35999)

The UGREEN CM511 (35999) is a six-port USB-C hub for users who want to connect more devices to a compatible laptop without relying on several individual adapters.

It combines one HDMI output, two USB-A data ports, two USB-C data ports and one USB-C Power Delivery input. These connections address common requirements for external displays, storage accessories and laptop charging.

The HDMI 2.0 output supports up to 3840 × 2160 at 60Hz when used with a compatible video-capable USB-C host, HDMI cable and monitor.

All four USB data ports support interface speeds up to 10Gbps, providing convenient connections for supported external SSDs, flash drives and other USB devices.

A separate USB-C PD input accepts up to 100W from a compatible charger, allowing supported laptops to receive charging power while using the hub.

With its aluminum construction and practical selection of connections, the CM511 is suited to everyday productivity, file management and portable laptop workstations.

Design & Performance

Compact Aluminum 6-in-1 Design for Everyday Work

The UGREEN CM511 (35999) features a compact aluminum housing designed for convenient use with compatible laptops and USB-C devices.

Its six downstream connections include one HDMI output, two USB-A data ports, two USB-C data ports and one dedicated USB-C PD input.

This configuration is useful for people who need both USB-A and USB-C peripherals connected at the same time.

The integrated USB-C host connection reduces the need to attach several separate adapters directly to a laptop.

Users can keep a monitor, storage devices and supported accessories connected through the hub during work sessions.

The CM511 is particularly suitable for compact desks, shared workspaces and portable laptop setups where a full-size desktop dock is unnecessary.

4K@60Hz HDMI 2.0 Output for External Monitors

The UGREEN CM511 provides one HDMI 2.0 output supporting resolutions up to 3840 × 2160 at 60Hz.

This allows users to connect a compatible external monitor, television or projector for a larger desktop workspace.

A high-resolution external screen can be useful for editing documents, working with spreadsheets, reviewing presentations and watching supported multimedia content.

The 60Hz refresh rate provides smoother everyday cursor and window movement than 30Hz when the full display mode is available.

To use HDMI output, the host computer's USB-C port must support video transmission, such as DisplayPort Alternate Mode, Thunderbolt or a compatible USB4 implementation.

Actual resolution and refresh rate depend on the host graphics capabilities, USB-C video mode, HDMI cable and connected display.

The CM511 has one HDMI output, so it does not provide two independent external HDMI monitor connections.

Dual USB-A 3.2 Ports with Up to 10Gbps Transfer

The CM511 includes two USB-A 3.2 data ports supporting theoretical interface speeds up to 10Gbps.

These ports are useful for connecting compatible USB flash drives, external SSDs and other high-speed storage devices.

Users can copy project files, documents, photos and other data between their laptop and connected storage.

The USB-A connections also support suitable keyboards, mice, USB receivers and other common peripherals.

This makes it possible to keep existing USB-A accessories in use even when a laptop has few built-in USB-A ports.

Actual transfer performance depends on the storage device, host connection, cable and workload. Multiple active devices share the available host bandwidth.

Dual USB-C 3.2 Data Ports for Modern Storage Devices

Alongside the two USB-A ports, the CM511 provides two USB-C 3.2 data ports supporting up to 10Gbps.

These connections are useful for compatible USB-C SSDs, external drive enclosures and other data accessories.

Users who work with both USB-A and USB-C storage can connect different devices without changing adapters.

The two USB-C data ports are intended for data transfer. They do not function as additional HDMI or DisplayPort video outputs.

They should also not be confused with the separate USB-C Power Delivery input used for laptop charging passthrough.

As with other USB connections, 10Gbps is the theoretical maximum interface speed. Actual file transfer rates depend on the connected devices and available shared bandwidth.

100W USB-C Power Delivery Charging Passthrough

The UGREEN CM511 (35999) includes a dedicated USB-C Power Delivery 3.0 input supporting up to 100W.

When connected to a suitable USB-C PD charger, the hub can pass charging power to a compatible laptop while its HDMI and USB data connections are in use.

This is convenient for laptops that have limited USB-C ports and need charging alongside external accessories.

The PD input supports a maximum input rating of 20V/5A, subject to compatible charging equipment.

The 100W rating refers to supported power input rather than a guaranteed 100W output to the laptop. Some power may be used by the hub itself.

Actual laptop charging power depends on the charger, USB-C cable, computer and supported Power Delivery profiles.

The dedicated PD port is for power input and does not support USB data transfer or video output.

Practical Compatibility for Laptop and Tablet Workstations

The UGREEN CM511 is designed for compatible USB-C laptops and other supported host devices.

It supports common USB data functions on suitable Windows, macOS and Linux systems, with display and charging functionality dependent on the host hardware.

Users can attach a monitor through HDMI, connect external storage through USB-A or USB-C, and supply charging power through the dedicated PD input.

These capabilities make the hub useful for office work, studying, presentations and file transfers.

Not every USB-C port supports the same features. Some USB-C ports provide data only, while others also support external displays and Power Delivery charging.

Before buying, confirm that your laptop supports the required USB-C video mode, USB data functions and charging capability.

The CM511 (35999) does not include an Ethernet port, SD/microSD card readers or a dedicated 3.5mm audio jack.

Who It's For

The UGREEN CM511 (35999) is suitable for office professionals who need a high-resolution external monitor and multiple USB accessories connected to a compatible laptop.

Students can use it for presentations, external storage and everyday study setups.

Home users may appreciate the combination of HDMI, USB-A and USB-C connections in one portable hub.

Users working with compatible external SSDs can benefit from the four 10Gbps USB data ports.

It is also useful for laptop owners who want USB-C charging passthrough without giving up their external display and USB accessory connections.

Why Buy From IT Source?

IT Source offers USB-C hubs, docking stations and computer connectivity accessories for customers in Bangladesh.

Customers can check the latest UGREEN CM511 (35999) price and availability before ordering.

The CM511 model name is used for multiple UGREEN product codes with different port arrangements. Confirm SKU 35999 when selecting this six-port configuration.

Contact IT Source Bangladesh for current product information and ordering assistance.
